All studies represented by the chromatogram below have been conducted utilizing Large Volume Static Headspace analysis on the 7650HS-CTS

The all-new 7650HS-CTS is the only commercially available solution that can quantify the consumer experience by taking an equilibrium “snapshot” of the headspace to accurately determine its composition from the lightest through the heaviest compounds. The 7650HS-CTS is truly unique as it is the industries “only” system that uses multiple stages of true capillary columns to perform headspace preconcentration.

Garlic Volatiles Analysis by GC/MS

h

Instrument: 7650HS-CTS
Run date: January 11, 2017
Sample description: Honey
Weight of sample (g): 10g
Sample conditions: 500mL vial with 2 hour equilibration at 25°C
Sample Amount: 250 cc
Split Mode: Splitless
Column: DB1 60m length x 0.32mm ID, 1.0 µm lm
Carrier: He, 2mL/min. constant flow
Oven Temp: 35°C hold 5min., 6°C/min. to 95°C, 10°C/min. to 140°C, 15°C/min. to 230 hold 4.5min.
GCMS: Agilent 7890A/5975C
MS Operation: 33-300 amu, 2.72 scans/sec

1. Carbon dioxide
2. Acetaldehyde
3. Ethanol
4. Acetone
5. 1,3-Pentadiene, (E)-
6. Isopropyl Alcohol
7. Dimethyl sulfide
8. Propanal, 2-methyl-
9. 2,3-Butanedione
10. 2-Butanone
11. Acetic acid
12. 3-Buten-2-ol, 2-methyl
13. Methane, bromochloro-
14. 1-Propanol, 2-methyl-
15. 2-Propen-1-ol, 2-methyl
16. Butanal, 3-methyl
17. Butanal, 2-methyl
18. 2-Propanone, 1-hydroxy
19. Benzene, 1,3-difluoro
20. Propanoic acid
21. Acetoin
22. 3-Buten-1-ol, 3-methyl-
23. 2-Butenal, 2-methyl-

24. Disulfide, dimethy
25. 2-Buten-1-ol, 2-methyl
26. Butanoic acid
27. 2-Butenal, 3-methyl
28. Hexanal
29. Furfural
30. Chlorobenzene-d5
31. 3-Hexen-1-ol
32. Ethanone, 1-(2-furanyl)-
33. Benzene, 1-bromo-3-fluoro
34. Benzaldehyde
35. 5-Hepten-2-one, 6-methyl
36. Octanal
37. D-Limonene
38. Benzyl alcohol
39. Benzeneacetaldehyde
40. cis-Linaloloxide
41. Nonanal
42. Phenylethyl Alcohol
43. Lilac aldehyde C
44. Benzenemethanol, .alpha.,.alpha.,4-trimethyl
45. Decanal
